More Details:

Compare the Sharp IR Sensors.

The GP2Y0A02YK0F has identical electronics to our GP2D12, but has special optics that give it a much longer detection range.

Absolute Maximum Ratings

Parameter	Symbol	Rating	Unit
Supply Voltage	V_CC	-0.3 to +7	V
Output Terminal Voltage	V_O	-0.3 to V_CC+0.3	V
Operating Temperature	T_opr	-10 to +60	°C
Storage Temperature	T_stg	-40 to +70	°C

Operating Supply Voltage

Parameter	Symbol	Rating	Unit	Remark
Operating Supply Voltage	V_CC	4.5 to 5.5	V

Electro-Optical Characteristics

Parameter	Symbol	Conditions	Min.	Typ.	Max.	Unit
Measuring distance range	delta L	^2 ^3	20	-	150	cm
Output Terminal Voltage	V_O	L = 150 cm ^*2	0.25	0.4	0.55	V
Output voltage difference	delta V_O	Output change at L change (150 cm -> 20 cm) ^*2	1.8	2.05	2.3	V
Average supply current	I_cc	-	-	33	50	mA

L: Distance to reflected object
^*2 Using reflected object: White paper (Made by Kodak Co. Ltd. gray cards
R-27, white face, reflective ratio: 90%)
^*3 Distance measuring range of the optical sensor system.
